4U Modular Boats (LW compatible)

from $50.00

Getting into 4U Modular shouldn’t be confusing or financially difficult! Our 4U Modular aluminum boats are offered as Passive or Powered. Powered boats supply up to 1A per rail, capable of powering two to four (in total) boats running analog based modules*.

Select Option:
Quantity:
Add To Cart

Getting into 4U Modular shouldn’t be confusing or financially difficult! Our 4U Modular aluminum boats are offered as Passive or Powered. Powered boats supply up to 1A per rail, capable of powering two to four (in total) boats running analog based modules*.

Getting into 4U Modular shouldn’t be confusing or financially difficult! Our 4U Modular aluminum boats are offered as Passive or Powered. Powered boats supply up to 1A per rail, capable of powering two to four (in total) boats running analog based modules*.

NOW SHIPPING!

Boats can have power distributed from one boat to another internally to simply power multiple boats off of one external 24Vdc power brick (wallwart).
Wooden desktop cheeks will be made available very soon for dual, triple and quad boat configurations! These are 4U Modular Format / LW Format compatible boats. Not Compatible w/ RS, STS or Buchla format modules

Looking for a portable rig? Check out the 12U pop-up cases that are available from various manufacturers.
Here’s one that’s quite affordable!

Active Options:
Active Rack Boat - Includes Rack ears + internal power supply (+/-12V @ 1000mA ) + passive power distribution board (turn key, comes w/ external wallwart)
Active Boat - Includes internal power supply (+/-12V @ 1000mA ) + passive power distribution board (turn key, comes w/ external wallwart) (Rack ears not included) (For use with wooden end cheeks or other mounting options, not included)

Passive Options:
Passive Rack Boat - Includes rack ears + assembled passive power distribution board
Passive Boat - Includes assembled passive power distribution board (Rack ears not included) (For use with wooden end cheeks or other mounting options, not included)

Active Boats can power up to four boats (1 active + 3 passive) of analog modules (digital modules tend to draw more current)

More info coming soon!

** 4U Modular is a term used for the format most commonly known as “Serge Format” or “Loudest Warning Format”. Out of respect for the ever growing format, 4U Modular is the easiest way to refer to it. More Specifically it refers to the panel height and mounting hole style. 4U Modular will patch up just fine with other 4U "Serge" formats such as "Random Source", but it will not mount in RS boats or Buchla Boats (or power off Buchla power for that matter). An info page about this will be added to the website soon to make this a lot more easy to understand.
